Go Back  Offshoreonly.com > Technical > General Q & A
Port side drive will not come up to trailer position? >

Port side drive will not come up to trailer position?

Like Tree2Likes

Port side drive will not come up to trailer position?

Reply

Old 07-05-2019, 01:31 PM
  #1
Gold Member
Gold Member
Thread Starter

WHOSNEXT's Avatar

Join Date: Nov 2003
Location: Hampton N.H.
My Boat: Looking $cash in hand$
Posts: 383
Default Port side drive will not come up to trailer position?

Both drives trim up and down fine, but when I'm ready to take the boat out of the water port side will not come up for trailer mode? what can I check?
WHOSNEXT is offline
Reply With Quote
Old 07-05-2019, 02:12 PM
  #2
Registered

Join Date: Sep 2013
Location: Wisconsin
My Boat: 2005 25 Outlaw, Whippled Merc 525, Imco SCX-4
Posts: 1,072
Default

Bravo drives I assume? Most likely the trim limit switch. Depending if this is a bravo or XR depends exactly where it is but it’ll near where the drive meets the helmet or on the pivots of the gimbal ring.
IGetWet is offline
Reply With Quote
Old 07-05-2019, 02:33 PM
  #3
Gold Member
Gold Member
Thread Starter

WHOSNEXT's Avatar

Join Date: Nov 2003
Location: Hampton N.H.
My Boat: Looking $cash in hand$
Posts: 383
Default

Originally Posted by IGetWet View Post
Bravo drives I assume? Most likely the trim limit switch. Depending if this is a bravo or XR depends exactly where it is but itíll near where the drive meets the helmet or on the pivots of the gimbal ring.
Yes its a bravo One. I'm going to open the switch up and see if its making good contact.
WHOSNEXT is offline
Reply With Quote
Old 07-05-2019, 03:22 PM
  #4
GPM
Registered

Join Date: Mar 2004
Location: Pa
My Boat: Sold my DCB
Posts: 2,417
Default

May be a separate relay for trailer switch
GPM is offline
Reply With Quote
Old 07-05-2019, 03:56 PM
  #5
Gold Member
Gold Member
Thread Starter

WHOSNEXT's Avatar

Join Date: Nov 2003
Location: Hampton N.H.
My Boat: Looking $cash in hand$
Posts: 383
Default

Originally Posted by GPM View Post
May be a separate relay for trailer switch
There is only one switch for both drives and the other drive works fine, unless the relay is on the pump?
WHOSNEXT is offline
Reply With Quote
Old 07-05-2019, 05:33 PM
  #6
Forum Regulator
VIP Member
iTrader: (1)

Sydwayz's Avatar

Join Date: May 2001
Location: Worldwide
My Boat: 17' Speedliner Cat & O.P.B.
Posts: 22,674
Default

FWIW, only a handful of builders use that capability. There is no issue with bypassing the trailer limit switch. .
IGetWet likes this.
Sydwayz is offline
Reply With Quote
Old 07-05-2019, 09:42 PM
  #7
Gold Member
Gold Member
Thread Starter

WHOSNEXT's Avatar

Join Date: Nov 2003
Location: Hampton N.H.
My Boat: Looking $cash in hand$
Posts: 383
Default


Originally Posted by Sydwayz View Post
FWIW, only a handful of builders use that capability. There is no issue with bypassing the trailer limit switch. .
how do I go about doing this?

WHOSNEXT is offline
Reply With Quote
Old 07-06-2019, 08:41 AM
  #8
VIP Member
VIP Member

Join Date: Nov 2002
Location: ankeny,ia.
Posts: 3,689
Default

Do you have HP transom assemblies?
JaayTeee is offline
Reply With Quote
Old 07-06-2019, 10:32 AM
  #9
Gold Member
Gold Member
Thread Starter

WHOSNEXT's Avatar

Join Date: Nov 2003
Location: Hampton N.H.
My Boat: Looking $cash in hand$
Posts: 383
Default

Originally Posted by JaayTeee View Post
Do you have HP transom assemblies?
Negative
WHOSNEXT is offline
Reply With Quote
Old 07-06-2019, 11:44 AM
  #10
VIP Member
VIP Member

Join Date: Nov 2002
Location: ankeny,ia.
Posts: 3,689
Default

maybe a wire came off of the trailer switch?
JaayTeee is offline
Reply With Quote
