How much HP? on my 454

Thread Tools

Old 12-12-2014 | 10:32 AM
  #21
Registered

Joined: Mar 2008
Posts: 1,181
Likes: 2
From: Vancouver BC
Default

Originally Posted by Black Baja
I was thinking more along the lines of trying to help a poor cylinder head out that's going to have a hard time keeping the fuel suspended in air as it travels through the port and in return keeping it out of detontion. Right or wrong? Like I said not the expert. Please enlighten me on this theory.
The best way to make use of a cylinder head that is larger then optimal, is to increase the rpm of the engine. To increase the rpm, you're going to need more duration, more duration will move the whole power curve up, a wider lobe sep will flatten the torque curve and make a broader power band. This can help in an application like this, and make it easier to prop the boat for all around performance. Also, the bigger duration cam will effect the idle, a wider lobe sep will help here too.
HaxbySpeed is offline
Reply
Old 12-12-2014 | 10:54 AM
  #22
Registered

Joined: Aug 2011
Posts: 2,733
Likes: 8
From: bel air, md
Default

Originally Posted by HaxbySpeed
The best way to make use of a cylinder head that is larger then optimal, is to increase the rpm of the engine. To increase the rpm, you're going to need more duration, more duration will move the whole power curve up, a wider lobe sep will flatten the torque curve and make a broader power band. This can help in an application like this, and make it easier to prop the boat for all around performance. Also, the bigger duration cam will effect the idle, a wider lobe sep will help here too.
Alex, if the lobe separation gives you a broader torque curve then why on engines that run in a small rpm window are they using 118-121 Lsa cams? Is it to move the torque curve way up in the motor? I don't know. Always wondered why.
Black Baja is offline
Reply
Old 12-12-2014 | 11:04 AM
  #23
SB
Registered
20 Year Member

Joined: Nov 2004
Posts: 14,090
Likes: 3,680
From: On A Dirt Floor
Default

Originally Posted by HaxbySpeed
Everyone benefits when good technical discussions take place. I'm laying in bed with a fever, so I need a distraction. Lol
Well, then let me help.

Both sets of these lobes, either when widened or put closer together, will increase pressure.

Guaranteed.

SB is offline
Reply
Old 12-12-2014 | 11:11 AM
  #24
Registered
20 Year Member

Joined: Jan 2006
Posts: 3,598
Likes: 1,168
From: taxachusetts
Default

454 semi closed chambered oval port 10.3-1 compr,vic jr oval intake.cam 230,236 ls110,flat tappet no less,made 527hp,517tq at 2 places,4100 and 5100rpm's.water dunoed at the end of the tails.carbs were 930 or 950cfm bolands,laws or something like that.anyone that rode in my boat could not believe how had the acceration was.any time from 30mph on up .
other thing they loved was blipping the throttle on the stand,,instant rev up,very,very responsive.
I loved those engines,,simple and fast.
sutphen 30 is offline
Reply
Old 12-12-2014 | 11:12 AM
  #25
SB
Registered
20 Year Member

Joined: Nov 2004
Posts: 14,090
Likes: 3,680
From: On A Dirt Floor
Default

Originally Posted by Black Baja
Alex, if the lobe separation gives you a broader torque curve then why on engines that run in a small rpm window are they using 118-121 Lsa cams? Is it to move the torque curve way up in the motor? I don't know. Always wondered why.
Are you talking Pro Stock here ?

Let me take a stab - super effecient cylinder heads,chambers and domes, very high compression, and a ton of rpm.
SB is offline
Reply
Old 12-12-2014 | 11:13 AM
  #26
Registered
20 Year Member

Joined: Jan 2006
Posts: 3,598
Likes: 1,168
From: taxachusetts
Default

oh and my tq curve was almost flat.
both engines after they were done in my boat were sold off to hot rod guys,,and they loved them.
sutphen 30 is offline
Reply
Old 12-12-2014 | 11:14 AM
  #27
Registered
20 Year Member

Joined: Jan 2006
Posts: 3,598
Likes: 1,168
From: taxachusetts
Default

Originally Posted by Black Baja
Alex, if the lobe separation gives you a broader torque curve then why on engines that run in a small rpm window are they using 118-121 Lsa cams? Is it to move the torque curve way up in the motor? I don't know. Always wondered why.
seems like the ls guys go the other way,115 down to 112 or less
sutphen 30 is offline
Reply
Old 12-12-2014 | 11:16 AM
  #28
Registered

Joined: Aug 2011
Posts: 2,733
Likes: 8
From: bel air, md
Default

Originally Posted by sutphen 30
454 semi closed chambered oval port 10.3-1 compr,vic jr oval intake.cam 230,236 ls110,flat tappet no less,made 527hp,517tq at 2 places,4100 and 5100rpm's.water dunoed at the end of the tails.carbs were 930 or 950cfm bolands,laws or something like that.anyone that rode in my boat could not believe how had the acceration was.any time from 30mph on up .
other thing they loved was blipping the throttle on the stand,,instant rev up,very,very responsive.
I loved those engines,,simple and fast.
Years ago I did a GM headed 496. Just over 10:1 it had a 110lsa with more duration. Baker Outlaw billet carb. Boat went 75+ in a hull that normally goes 70 with an hp500. That thing pulled like crazy when you hit it.
Black Baja is offline
Reply
Old 12-12-2014 | 11:18 AM
  #29
Registered

Joined: Aug 2011
Posts: 2,733
Likes: 8
From: bel air, md
Default

Originally Posted by SB
Are you talking Pro Stock here ?

Let me take a stab - super effecient cylinder heads,chambers and domes, very high compression, and a ton of rpm.
Yep. I've seen a few of ex-prostock motors pulled apart some were 118 some 121
Black Baja is offline
Reply
Old 12-12-2014 | 11:20 AM
  #30
Registered

Joined: Aug 2011
Posts: 2,733
Likes: 8
From: bel air, md
Default

Originally Posted by SB
Are you talking Pro Stock here ?

Let me take a stab - super effecient cylinder heads,chambers and domes, very high compression, and a ton of rpm.
I was always told bad head needs help from the camshaft (tight lsa) good head doesn't.
Black Baja is offline
