45' Wellcraft Excalibur - Need input on Drive and Engine upgrade ideas
#31
I say work out the weak link first, then go for the HP next winter. Im running my stock Bravos like they are made of glass until I decide to go back to work and have money flowing in and not out. Just finished the restoration on my Exal this week. Ah who am I kidding, when is a project ever done?
Nah....
#32
Registered

Joined: Jan 2006
Posts: 3,869
Likes: 797
From: St. Pete Beach, FL
the whole point of my conversion is to get away from Bravo style drives, spent far too much money and time swapping drives, prop tuning and trying to get it right. Blew 5 drives.
I got a great deal on the low hour fresh water Arnesons from a boat partout. I couldn’t buy SCX’s and props for less.
Im a big fan of surface drives, been wanting to try them for 20 years and this is the perfect opportunity to do so.
The reliability and speed increase is what I’m after.
I got a great deal on the low hour fresh water Arnesons from a boat partout. I couldn’t buy SCX’s and props for less.
Im a big fan of surface drives, been wanting to try them for 20 years and this is the perfect opportunity to do so.
The reliability and speed increase is what I’m after.
#33
Registered
Joined: Mar 2007
Posts: 121
Likes: 70
From: SW Florida
No kidding. Wrapped the transom in a navy blue metallic yesterday. Tomorrow, recovering the small ceiling panels right when you walk into the rear bed room and the small one at the head of the bed. OH.......and the toilet pump started to run non stop again after I replaced every component sans the pressure tank and the line from the toilet to the vacuum tank. Good thing the wife is out of town for a week so I get to work on the boat, go to the range to shoot stuff, hit the local sprint car track and a new friend introduced me to KartCross............I need one of those like a hole in the head. He has two racers and I think im hooked.
#34
Thread Starter
Registered
Joined: Jul 2020
Posts: 5
Likes: 0
Update - Unfortunately, it looks like I'm going the vanilla route. The issue wasn't budget, but after talking to various shops and having everyone of them try to talk me out of it, I gave in. I'm going to freshen the 502's top ends and convert the Bravo 3's over to Bravo 1 x's. The shop I'm using has converted 2 45 Excalibur's over to the Bravo 1x's with great results. I'm also going to add the big K-tabs, the plates on there now are nearly worthless. This boat is a day cruiser and on fresh motors it should cruise between 38-40 and do 50+ at WOT. I'm good with that.
#35
Registered

Joined: Oct 2005
Posts: 300
Likes: 61
From: Boston MA
I would NOT put a Bravo 1x on this boat. You will be disappointed in overall performance. Before putting Arnesons on mine I ran the Bravo 3 at a 2.0 ratio. In doing that you can use the Bravo XR gear set in the upper. Much stronger. If your Bravo case doesnt have a tower in it you can have MAX Machine worx install one or just buy new upper Bravo XR upper case with gears and install your Bravo 3 lover to it. I ran 700hp (60mph) on this set up for years. I changed the gears every season due to load wear not breakage.
#36
Registered
Joined: Jul 2009
Posts: 8,527
Likes: 706
From: Taunton Ma
A 400 Ss formula is much smaller than the Excalibur, and they eat drives. Sonic 30 wasted a bunch of drives in a couple short seasons. Proof enough to me that bravos are a horrible idea on that boat.
#37
Thread Starter
Registered
Joined: Jul 2020
Posts: 5
Likes: 0
I would NOT put a Bravo 1x on this boat. You will be disappointed in overall performance. Before putting Arnesons on mine I ran the Bravo 3 at a 2.0 ratio. In doing that you can use the Bravo XR gear set in the upper. Much stronger. If your Bravo case doesnt have a tower in it you can have MAX Machine worx install one or just buy new upper Bravo XR upper case with gears and install your Bravo 3 lover to it. I ran 700hp (60mph) on this set up for years. I changed the gears every season due to load wear not breakage.
Let me ask this, I run this boat on The Lake of the Ozarks, it handles the big water great, but I need it to be able to maneuver in some tight spaces and slips. I store the boat at my dock on a back-up lift. I hear Arneson drives really make it hard to drive at low speeds. True?
#38
Thread Starter
Registered
Joined: Jul 2020
Posts: 5
Likes: 0
I would NOT put a Bravo 1x on this boat. You will be disappointed in overall performance. Before putting Arnesons on mine I ran the Bravo 3 at a 2.0 ratio. In doing that you can use the Bravo XR gear set in the upper. Much stronger. If your Bravo case doesnt have a tower in it you can have MAX Machine worx install one or just buy new upper Bravo XR upper case with gears and install your Bravo 3 lover to it. I ran 700hp (60mph) on this set up for years. I changed the gears every season due to load wear not breakage.
#39
Registered

Joined: Oct 2005
Posts: 300
Likes: 61
From: Boston MA
The boat handles and drives better with the Arneson vs the Bravo. Docking was way better with the Arneson I put the Arneson 7M on mine same as Sonic30 is doing on his. But that is a project to install correctly and will cost some money. My advise is to build Bravo 3XR drives and change the fluid every 15-20 hrs is your staying with stock horsepower.
#40
Registered
Joined: May 2012
Posts: 60
Likes: 77
Arneson ASD #8 surface drive is what we use on 42', 20,000 lb, Cigarette type hull with Cat 3126/420HP Diesels. For that hull u might need more HP but the ASD #8, can handle lots more. Highly recommend this set up. We have many years on the drivetrain near flawless performance.. Always get 1 KMPG or more. Very

Low maintenance

Low maintenance
